Iron Mass Density Cheat Sheet for Students and Engineers

Iron in its pure form has a mass density (density) of 7.874 g/cm³ or 7,874 kg/m³, measured at room temperature (20°C). Iron is about 7.9 times denser than water. The density of iron varies a bit depending on the kind of iron. The least dense one, gray cast iron, has a density of about 6.8 g/cm³; while the densest one is pure wrought iron, having a density close to that of pure iron at 7.87 g/cm³.

What Exactly is Mass Density?

Mass density is measured by how much mass is in a given volume. The mathematical equation for it is straightforward:

ρ (Density) = m (Mass) ÷ V (Volume)

Iron is usually referenced and presented in different units: density of iron (kg/cm³) or (kg/m³). All these units are describing the same physical quantity with different scales.

Density of Various Iron Types

You cannot say all iron is the same; the manufacturing process and carbon content have the effect of shifting the density value:

Iron Type	Density (g/cm³)	Density (kg/m³)
Pure iron (Fe)	7.874	7,874
Wrought iron	7.75–7.88	7,750–7,880
Cast iron (gray)	6.80–7.20	6,800–7,200
Cast iron (ductile)	7.10–7.30	7,100–7,300
Steel (carbon)	7.75–7.87	7,750–7,870

The lowest density is measured in cast iron, but it is still a very dense material because it contains graphite flakes and internal porosity that lowers the actual mass per unit volume slightly. Cast iron is the least dense because it has graphite flakes plus internal porosity that lowers the total mass per unit volume.

Importance of Iron Density



Iron workers, material scientists, mechanical engineers, and students have many good reasons to determine the density of iron:


• Material selection, to find out the weight-strength ratios of different materials for structural or industrial engineering.
• Casting prediction, to estimate the volume of molten metal needed to totally or partially fill a mold that has an identified volume.
• Shipping and logistics to calculate the total weight of the load by finding Iron Mass Density volume, and thus make transportation arrangements.
• Solving problems in physics and chemistry, working out mass, volume, or density in your lessons.

Deducing the Density of a Piece of Iron

A piece of iron with any shape can be tested for density by going through three stages:

• Weigh the object with a balance to get mass in grams or kilograms.
• Determine the Iron Mass Density . If it is a regular shape, do it by geometrical formulas (length × width × height); if it isn’t, measure it in an Eureka can filled with water and find its displaced volume instead.
• Mass divided by the Iron Mass Density to compute density expressed in g/cm³ or kg/m³.

Real-life Case

A piece of solid iron is a cube with 2 cm on each side, which weighs 63 grams in total.

• Volume = 2 × 2 × 2 = 8 cm³
• Density = 63 g ÷ 8 cm³ = 7.875 g/cm³

This is in excellent agreement with the density of commercially pure cast iron, so we are fairly sure we had been dealing with it, and there was no mixture with steel or iron alloys.

Iron Density vs. Other Common Metals

When comparing the mass of iron relative to different metals, you get a better understanding:

MetalMass (g/cm³)Aluminum2.70Titanium4.51Iron7.874Copper8.96Lead11.34Gold19.32

Iron comes in at the middle to slightly upper side when it comes to weight relative to various construction materials Iron Mass Density is denser than aluminum and titanium, but lighter than copper, lead, or gold.

How is the Density of Iron Affected by Temperature?



Indeed. The heating process slightly enlarges and therefore reduces the density of most metals, including iron. Molten iron at Iron Mass Density melting point of (1, 538°C) is only about 6.98 g/cm³, which is a lowering of 11% against the room temperature solid form. Due to this reason, foundries usually compensate for the thermal expansion in their volume calculations so the shrinking that happens as casting iron cools down and solidifies does not affect the final product volume.

FAQs

1. How dense can you get with iron in kg/m3?

 Pure Fe’s density under standard conditions is 7, 874 kg/m³.

2. Is iron less or more dense than steel?

You can say iron and steel are very close, as steel is largely iron. Carbon steel, for example, runs about from 7, 750, 7, 870 kg/m³, which slightly falls under the density of pure iron.

3. Besides, the cast iron is less dense than pure iron.

The porosity and presence of graphite in cast iron contribute to a lower overall density, which is why it is lighter than pure iron for the same volume.

4. How many kilograms is one cube of iron?

A cube one cube is a unit of measure and one cubic meter of pure iron would weigh about 7 thousand 8 hundred 74 kilograms, which is also roughly 7.87 metric tons.


Latest Article: Lesson 24 Percent and Rates Per 100 Complete Guide For Students


Highlight

• At 20 degrees Celsius, Fe has a density of 7.874 grams per milliliter, which is also 7 thousand 8 hundred 74 kilograms per cubic meter.
• Cast iron is lighter mainly because of the presence of graphite and other substances, resulting in porosity.
• It is easy to calculate a substance’s density by dividing mass by volume and this comes in handy when doing projects related to engineering and schoolwork.
• A 11% difference in the density exists between solid iron and molten iron.

Iron’s mass density is 7.874 g/cm³ (7,874 kg/m³) at room temperature. See how it compares to steel, cast iron, and other metals, plus how to calculate it.
